Oil Pan for 2011 Suzuki Grand Vitara

N/A

Oil Pan Baffle

11540-78K00

Suzuki

Description: Grand Vitara. Kizashi.

View Details

N/A

Bearings

12227-78K00

Suzuki

Description: Grand Vitara. No.1. Kizashi.

View Details

N/A

Bearings

12227-78K50

Suzuki

Description: Grand Vitara. No.2. Kizashi.

View Details

N/A

Engine Camshaft Bearing

12730-78810

Suzuki

Description: Set. Grand Vitara. Kizashi.

$98.84

N/A

Oil Pick-Up

16520-78K00

Suzuki

Description: Grand Vitara. 2.4L.

$93.27

N/A

Rear Mount

11710-65J10

Suzuki

Description: 2.4L, 2wd. Grand Vitara. 2wd. 3.2L, 2wd.

$124.53

N/A

Rear Mount

11710-65J00

Suzuki

Description: 2.4L, 4wd. 2.7L. Grand Vitara. 3.2L, 4wd.

$152.92

N/A

Front Mount

11610-78K02

Suzuki

Description: 2.4L. Grand Vitara. Right.

$590.22

N/A

Control Valve Solenoid

16550-51KA0

Suzuki

Description: SX4. Grand Vitara. Kizashi.

$293.53

N/A

Overhaul Gasket Set

11400-66822

Suzuki

Description: Grand Vitara.

$198.11

N/A

Short Block

1100078811

Suzuki

Description: Grand Vitara.

View Details

N/A

Valve Guide

11115-54G00-001

Suzuki

Description: Grand Vitara.

$36.67

1

Cylinder Block

11200-78K31

Suzuki

Description: Grand Vitara.

View Details

2

Cylinder Head

11100-78KA0

Suzuki

Description: Grand Vitara. Kizashi.

$2,516.59

3

Head Gasket

11141-78K01

Suzuki

Description: Kizashi. Grand Vitara. Right.

$149.01

4

Valve Cover

11170-78K00

Suzuki

Notes: Includes Valve Cover Gasket.

Description: 2010-13. SX4. 2.4L. Grand Vitara. Kizashi.

$461.81

5

Valve Cover Gasket

11189-78K10

Suzuki

Description: SX4. 2010-13. Grand Vitara. Kizashi.

$75.74

6

Valves

12915-78K00

Suzuki

Description: Grand Vitara. Exhaust. Kizashi.

$44.39

6

Valves

12911-78K00

Suzuki

Description: Grand Vitara. Intake. Kizashi.

$44.39

7

Valve Spring Seats

12933-69G10

Suzuki

Description: SX4. Grand Vitara. Kizashi.

View Details

8

Valve Seals

09289-05012

Suzuki

Description: SX4. Swift. Esteem. Kizashi. Vitara. Sidekick.

$8.32

9

Valve Springs

1292178K00

Suzuki

Description: SX4. Grand Vitara. Kizashi.

View Details

10

Valve Spring Retainers

12931-78G00

Suzuki

Description: SX4. Grand Vitara. Kizashi.

View Details

11

Valve Keeper

12932-24400

Suzuki

Description: SX4. Swift. Esteem. Kizashi. Vitara. Exhaust valve. Sidekick.

View Details

12

Valve Lifters

12891-78K00-260

Suzuki

Notes: Order By Thickness.

Description: SX4. Grand Vitara. Kizashi.

View Details

13

Exhaust Camshaft

12721-78K00

Suzuki

Description: SX4. Grand Vitara. Exhaust. Kizashi.

$447.72

13

Intake Camshaft

12710-78K00

Suzuki

Description: SX4. Grand Vitara. Intake.

$620.03

14

Camshaft Gear

12742-78K00

Suzuki

Description: SX4. Exhaust. Grand Vitara. Kizashi.

$42.88

15

Timing Chain

12761-78K00

Suzuki

Description: 2010-13. SX4. All. Grand Vitara. Kizashi.

$283.28

16

Tensioner

12831-69J00

Suzuki

Description: 2010-13. Timing chain. SX4. Grand Vitara. Kizashi.

$245.82

17

Tensioner Guide

12811-78K01

Suzuki

Description: SX4. Grand Vitara. Kizashi.

$100.03

18

Chain Guide

12771-78K01

Suzuki

Description: Timing chain. SX4. Grand Vitara. Kizashi.

$55.87

19

Crankshaft Gear

12631-54L00

Suzuki

Description: SX4. Grand Vitara. Kizashi.

$96.21

20

Front Cover

11380-54L01

Suzuki

Description: SX4. 2010-13. Grand Vitara. 2.4L, from eng 1045793. Kizashi.

$495.87

21

Camshaft Gear

12740-78K00

Suzuki

Description: SX4. Intake (actuator). Grand Vitara. Kizashi.

$778.61

22

Balance Shaft

12230-78K01

Suzuki

Description: Grand Vitara. No.1. Kizashi.

$274.97

22

Balance Shaft

12240-78K00

Suzuki

Description: Grand Vitara. No.2. Kizashi.

$258.67

23

Piston Rings

12140-78K00

Suzuki

Notes: Includes Ring Set For One Cylinder.

Description: Grand Vitara. Kizashi.

$120.75

24

Piston

12100-78831-0A0

Suzuki

Notes: Includes One Piston W/Pin.

Description: Grand Vitara. Mark 1. Kizashi.

$146.65

24

Piston

12100-78831-0B0

Suzuki

Notes: Includes One Piston W/Pin.

Description: Grand Vitara. Mark 2. Kizashi.

$137.39

25

Connecting Rod

12160-78K20

Suzuki

Description: SX4. Grand Vitara. Kizashi. Incl.Bolts.

$185.14

26

Bearings

12100-78840-0C0

Suzuki

Notes: Includes One Upper & Lower Bearing For One Rod.

Description: SX4. Grand Vitara. Std t:1.5. Non color. Kizashi.

$35.68

26

Bearings

12100-78840-0E0

Suzuki

Notes: Includes One Upper & Lower Bearing For One Rod.

Description: SX4. Blue. Grand Vitara. Std t:1.5. Kizashi.

$35.68

26

Bearings

12100-78840-025

Suzuki

Notes: Includes One Upper & Lower Bearing For One Rod.

Description: Grand Vitara. Us 0.25/t:1.625. Kizashi.

$35.68

26

Bearings

12100-78840-0A0

Suzuki

Notes: Includes One Upper & Lower Bearing For One Rod.

Description: SX4. Green. Grand Vitara. Std t:1.5. Kizashi.

$35.68

26

Bearings

12100-78840-0D0

Suzuki

Notes: Includes One Upper & Lower Bearing For One Rod.

Description: SX4. Yellow. Grand Vitara. Std t:1.5. Kizashi.

$35.68

26

Bearings

12100-78840-0B0

Suzuki

Notes: Includes One Upper & Lower Bearing For One Rod.

Description: SX4. Black. Grand Vitara. Std t:1.5. Kizashi.

$35.68

27

Front Crank Seal

09283-41003

Suzuki

Description: Grand Vitara.

View Details

28

Bearings

12301-78820-0D0

Suzuki

Notes: Includes: One Upper & Lower Bearing.

Description: SX4. Yellow. Grand Vitara. Std t:2. Kizashi.

$45.23

28

Bearings

12301-78820-0BA

Suzuki

Notes: Includes: One Upper & Lower Bearing.

Description: Kizashi. Us 0.25/t:2.125. Red/black. Grand Vitara.

View Details

28

Bearings

12301-78820-0C0

Suzuki

Notes: Includes: One Upper & Lower Bearing.

Description: SX4. Grand Vitara. Std t:2. Non color. Kizashi.

$45.23

28

Bearings

12301-78820-0CA

Suzuki

Notes: Includes: One Upper & Lower Bearing.

Description: Kizashi. Us 0.25/t:2.125. Red. Grand Vitara.

View Details

28

Bearings

12301-78820-0DA

Suzuki

Notes: Includes: One Upper & Lower Bearing.

Description: Grand Vitara. Us 0.25/t:2.125. Red/yellow. Kizashi.

View Details

28

Bearings

12301-78820-0E0

Suzuki

Notes: Includes: One Upper & Lower Bearing.

Description: SX4. Blue. Grand Vitara. Std t:2. Kizashi.

$42.39

28

Bearings

12301-78820-0EA

Suzuki

Notes: Includes: One Upper & Lower Bearing.

Description: Kizashi. Us 0.25/t:2.125. Red/blue. Grand Vitara.

View Details

28

Bearings

12301-78820-0B0

Suzuki

Notes: Includes: One Upper & Lower Bearing.

Description: SX4. Black. Grand Vitara. Std t:2. Kizashi.

$45.23

28

Bearings

12301-78820-0AA

Suzuki

Notes: Includes: One Upper & Lower Bearing.

Description: Kizashi. Us 0.25/t:2.125. Red/green. Grand Vitara.

View Details

28

Bearings

12301-78820-0A0

Suzuki

Notes: Includes: One Upper & Lower Bearing.

Description: SX4. Green. Grand Vitara. Std t:2. Kizashi.

$45.23

29

Thrust Bearing

12300-78890

Suzuki

Description: SX4. Esteem. Std t:2.5. Kizashi. Standard. Vitara. Sidekick.

$31.64

29

Thrust Bearing

12300-78890-012

Suzuki

Description: Grand Vitara. 0s 0.125/t:2.563. Kizashi. O.s 0.125.

View Details

30

Crankshaft

12220-78K00

Suzuki

Description: Grand Vitara. Kizashi.

$1,394.45

31

Crankshaft Pulley

12610-78K00

Suzuki

Description: 2010-13. SX4. 2.4L. Grand Vitara. Kizashi.

$190.86

32

Rear Main Seal

09283-98003

Suzuki

Description: SX4. Grand Vitara. Kizashi.

$50.45

33

Oil Pan

11511-78K01

Suzuki

Description: 2.4L. Grand Vitara. Upper.

$723.51

34

Oil Pump

16100-78K01

Suzuki

Notes: Includes: Both Balance Shafts, Gears, Upper & Lower Housing, Bearings And Oil Pump Assy.

Description: Grand Vitara. Kizashi.

$1,238.09

35

Oil Pump Gear

16113-78K00

Suzuki

Description: Grand Vitara. Kizashi.

$62.03

36

Chain

16760-78K00

Suzuki

Description: Grand Vitara. Kizashi.

$71.11

37

Tensioner

16770-78K03

Suzuki

Description: Grand Vitara. Kizashi.

$171.73

38

Oil Pump Cover

16160-78K00

Suzuki

Description: Grand Vitara. Kizashi.

$13.09
