Controls for 2003 Suzuki Grand Vitara
No.
Part # / Description / Price
Price
1
2
Evaporator Assembly
Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front. 2003-05.
3
Evaporator Core Suzuki
Suzuki Notes: PARTS: Part included with evaporator assembly.
Description: XL-7. 2003-06, front. For Primary HVAC. 2003-05. Grand Vitara.
4
Evaporator Core Grommet Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front. 2003-05.
5
Upper Case Suzuki
Suzuki Positions: Left
Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, with climate control. 2003-05.
5
Upper Case Suzuki
Suzuki Positions: Right
Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, with climate control. 2003-05.
6
Lower Case Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front. 2003-05.
7
Duct Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front. 2003-05.
8
Door Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, vent. 2003-05, vent.
9
Door Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, defroster. 2003-05, defroster.
10
Door Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, foot. 2003-05, foot.
11
Door Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, air mixture. 2003-05, air mixture.
12
Door Actuator Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: Grand Vitara, XL-7. Mode actuator. 2003-06, front, mode. 2003-05, mode.
13
Door Actuator Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: Grand Vitara, XL-7. Temp actuator. 2003-06, front, temp. 2003-05, temp.
14
Lever Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, main mold. 2003-05, main mold.
15
Lever Suzuki
Suzuki Positions: Right
Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, vent. 2003-05, vent.
15
Lever Suzuki
Suzuki Positions: Left
Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, vent. 2003-05, vent.
16
Lever Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, defroster, outer. 2003-05, defroster, outer.
17
Lever Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, defroster, inner. 2003-05, defroster, inner.
18
Lever Suzuki
Suzuki Positions: Left
Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, foot. 2003-05, foot.
18
Lever Suzuki
Suzuki Positions: Right
Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, foot. 2003-05, foot.
19
Lever Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, lower foot. 2003-05, lower foot.
20
Lever Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front, air mixture main. 2003-05, air mixture main.
21
Packing Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front. 2003-05.
22
Seal Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front. 2003-05.
23
Cover Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front. 2003-05.
24
Expansion Valve Suzuki
Suzuki Notes: PARTS: Part included with evaporator assembly.
Description: Grand Vitara, XL-7. 2003-06, front. 2003-05. For Primary HVAC.
25
HVAC Evaporator Temperature Switch Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: XL-7. Front. 2003-05. Grand Vitara.
26
Heater Core Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: XL-7. 2003-06, front. Grand Vitara. 2003-05.
27
Temp Sensor Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front. 2003-05.
28
Side Cover Suzuki
Suzuki Notes: PARTS: Part included with AC and heater assembly.
Description: 2003-06, front. 2003-05.
29
Side Cover Seal Suzuki
Suzuki Notes: PARTS: Part included with side cover.
Description: 2003-06, front. 2003-05.
Related Parts
Part # / Description / Price
Price
Dash Control Unit Suzuki
Suzuki Description: Grand Vitara, XL-7. Heater/ac switch. 2003-06, with climate control. 2003-05, with auto ac.
